Self-Contained Standard Precipitators - Model Series: Mi (with Integral Blower/Motor Assembly)- 800 Though 6000 CFM
Mi-series: This product range is self-contained, utilizing its own built in squirrel cage blower and motor assembly. Typically the units are free standing or suspended from the ceiling. Source capture applications use a pickup hose assembly to draw mist or smoke directly from it source and into the precipitator for cleaning much like a vacuum cleaner. Mi-series units are built only with industrial cells as described above under the I-series. Blower and motor assemblies are designed to accommodate the SCFM throughput of the application with consideration for internal and external static pressure losses. Mi-series housings are made of cold rolled steel that is primed and finished in enamel. Single tier and two tier configurations are available in sizes ranging from 800-CFM to 6000-CFM.
Mi-series: This product range is self-contained, utilizing its own built in squirrel cage blower and motor assembly. Typically the units are free standing or suspended from the ceiling. Source capture applications use a pickup hose assembly to draw mist or smoke directly from it source and into the precipitator for cleaning much like a vacuum cleaner. Mi-series units are built only with industrial cells as described above under the I-series. Blower and motor assemblies are designed to accommodate the SCFM throughput of the application with consideration for internal and external static pressure losses. Mi-series housings are made of cold rolled steel that is primed and finished in enamel. Single tier and two tier configurations are available in sizes ranging from 800-CFM to 6000-CFM.
Item # |
Nominal Rating |
Height |
Length |
Width |
Motor Power |
---|---|---|---|---|---|
Mi-8 | N/A 22.7 m³/min800 cfm | N/A 23 in | N/A 41.5 in | N/A 19 in | N/A 1/4 hp |
Mi-10 | N/A 28.3 m³/min1000 cfm | N/A 23 in | N/A 41.5 in | N/A 23 in | N/A 1/4 hp |
Mi-12 | N/A 34 m³/min1200 cfm | N/A 23 in | N/A 41.5 in | N/A 26.563 in | N/A 1/3 hp |
Mi-16 | N/A 45.3 m³/min1600 cfm | N/A 23 in | N/A 41.5 in | N/A 36 in | N/A 1/3 hp |
Mi-20 | N/A 56.6 m³/min2000 cfm | N/A 23 in | N/A 41.5 in | N/A 44.375 in | N/A 1/2 hp |
Mi-24 | N/A 68 m³/min2400 cfm | N/A 23 in | N/A 41.5 in | N/A 51.25 in | N/A 1/2 hp |
Mi-30 | N/A 85 m³/min3000 cfm | N/A 23 in | N/A 41.5 in | N/A 65.63 in | N/A 1/4 hp |
Mi-36 | N/A 101.9 m³/min2600 cfm | N/A 23 in | N/A 41.5 in | N/A 75.25 in | N/A 1 hp |
Mi-40 | N/A 113.3 m³/min4000 cfm | N/A 41.25 in | N/A 41.5 in | N/A 44.375 in | N/A 1 hp |
Mi-48 | N/A 135.9 m³/min4800 cfm | N/A 41.25 in | N/A 41.5 in | N/A 51.25 in | N/A 1 hp |
Mi-60 | N/A 170 m³/min6000 cfm | N/A 41.25 in | N/A 41.5 in | N/A 65.75 in | N/A 1.5 hp |
